Mechanical
Dimensions: 100 x 100 x 27 mm (3.9 x 3.9 x 1.1″)
Weight: 220 g (0.49 lb)
Enclosure material: UV-stabilized polycarbonate
Hardware
Networking interface:
1x SC/APC, ITU-G.9807 XGSPON WAN port
1x 100/1,000/2,500/5,000/10,000 MbE RJ45 LAN ports
Management interface:
Ethernet in-band
PON
Memory: 256 MB DDR
Onboard flash storage: 32 MB NOR
Max. power consumption: 8W
Power method: USB-C 5V DC, 3A
Power supply: 5V DC, 3A power adapter
Supported voltage range: 5V DC power adapter
Total non-blocking line rate:
Downstream: 9.95 Gbit/s
Upstream: 9.95 Gbit/s
Normal TX range of optical module: 4 to 9dBm
Normal RX range of optical module: -9 to -26dBm
Button: 1 Factory reset
Ambient operating temperature: -15 to 45° C (5 to 113° F)
Ambient operating humidity: 10 to 95% non-condensing
Certifications: CE, FCC, IC
Fiber
Operating wavelength: TX: 1,270nm
RX: 1,577nm
Line code: Scrambled NRZ
Physical reach: 20 km
