**Hardware**
Networking interface
1x SC/APC, ITU-G.984 GPON WAN port
4x GbE RJ45 LAN ports
WiFi: 802.11ax 5/2.4 GHz channels
Management interface:
Ethernet In-Band
PON
Power method:
USB-C 5V DC, 3A
24V passive PoE, 0.5A
Power supply:
5V DC, 3A power adapter, 1.5 m cord (included)
Supported voltage range:
10–30V DC (passive PoE)
5V DC (adapter)
Max. power consumption: 11W
Total non-blocking line rate
Downstream: 2.488 Gbps
Upstream: 1.244 Gbps
Normal range of optical module
TX: 0.5 to 5 dBm
RX: -8 to -28 dBm
Max. WiFi TX power
2.4 GHz: 20 dBm
5 GHz: 20 dBm
MIMO
2.4 GHz: 2 x 2
5 GHz: 2 x 2
Max. WiFi radio rate
2.4 GHz: 300 Mbps
5 GHz: 1.2 Gbps
Antenna gain
2.4 GHz: 1 dBi
5 GHz: 3 dBi
Ambient operating temperature: -15 to 45° C (5 to 113° F)
Ambient operating humidity: 10 to 90% noncondensing
Certifications: FCC, IC, CE
