Includes Poe Injector
The PowerBeam ac directs RF energy in a tighter beamwidth. With the focus in one direction, the PowerBeam ac blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Mechanical
Dimensions: 620 x 620 x 386 mm (24.4 x 24.4 x 15.2″)
Weight: 6.4 kg (14.1 lb)
Enclosure material: Outdoor UV-stabilized plastic
Mounting: Pole mount kit (Included)
Wind loading: Without radome: 1510 N at 200 km/h (340 lbf at 125 mph), With radome: 1830 N at 200 km/h (411 lbf at 125 mph)
Wind survivability: 200 km/h (125 mph)
Hardware
Networking interface: (1) GbE RJ45 port
Power method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply: 24V, 0.5A gigabit PoE adapter (Included)
Supported voltage range: 20-27V DC
Max. power consumption: 8.5W
ESD/EMP protection: Air/contact: ± 24 kV
LEDs: (1) Power, (1) LAN, (4) WLAN
Signal strength LEDs: Software-adjustable to correspond to custom RSSI levels
Salt fog test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G method 509.5
Vibration test: IEC 68-2-6
Temperature shock test: IEC 68-2-14
UV test: IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-driven rain test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G method 506.5
Ambient operating temperature: -40 to 70° C (-40 to 158° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: FCC, IC, CE, RoHS
System
Gain: 29 dBi
Max. VSWR: 1.6:1
Channel sizes: PtP Mode: 10/20/30/40/50/60/80 MHz, PtMP Mode: 10/20/30/40 MHz
Polarization: Dual linear
