Mechanical
Dimensions: 358 x 271.95 x 272.5 mm (14.1 x 10.7 x 10.7″)
Weight: Without mount: 800 g (1.8 lb)
With mount 980 g (2.2 lb)
Wind survivability: 200 km/h (125 mph)
Wind loading: 275 N at 200 km/h (61.8 lbf at 125 mph)
Hardware
Networking interface: (1) GbE RJ45 port
Power method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power supply: 24V, 0.3A gigabit PoE adapter (Included)
Supported voltage range: 22–27V DC
Max. power consumption: 7W
Max. power output: 25 dBm
Gain: 23 dBi
Ambient operating temperature: -40 to 70° C (-40 to 158° F)
Ambient operating humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC
