Appearance
Dimensions: Double-sided 80 mm x 22 mm x 3.58 mm (3.15″ x 0.87″ x 0.14″)
Weight: 8 g (0.28 oz)
Type: M.2 2280
Interface
Bus Interface: NVMe PCIe Gen3 x4
Storage
Flash Type: QLC NAND flash
Capacity: 500 GB
Operating Environment
Operating Temperature: 0°C (32°F) ~ 70°C (158°F)
Operating Voltage: 3.3V±5%
Performance
Sequential Read/Write (CrystalDiskMark): up to 1,900/900 MB/s
4K Random Read/Write (IOmeter): up to 90,000/200,000 IOPS
Terabytes Written (TBW): 500 GB
Mean Time Between Failures (MTBF): 2,000,000 hour(s)
Drive Writes Per Day (DWPD): 0.27 (3 yrs)
Note:
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Terabytes Written (TBW) expresses the endurance under the highest capacity.
Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
