TL-WR820N is compatible with IEE 802.11b/g/n and provides a high-speed Wi-Fi. Enjoy speeds of up to 300 Mbps for even your most demanding home networking needs, such as HD streaming, online gaming, and downloading large files.
- 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work
- IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
- Compatible with IPv6 (Internet Protocol version 6)
- Guest Network provides separate access for guests while securing the host network
- Parental Controls manage when and how connected devices can access the internet
- Security protocols protect your home network with firewalls and wireless encryption
WIRELESS
Standards: Wi-Fi 4
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds: N300
2.4 GHz: 300 Mbps (802.11n)
WiFi Range: 2 Bedroom Houses2× Fixed Antennas
WiFi Capacity: Legacy
Working Modes: Router Mode
HARDWARE
Processor: Single-Core CPU
Ethernet Ports: 1× 10/100 Mbps WAN Port
2× 10/100 Mbps LAN Ports
Buttons: WPS/Reset Button
Power: 5 V ⎓ 0.6 A
SECURITY
WiFi Encryption: WEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security: SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network: 1× 2.4 GHz Guest Network
SOFTWARE
Protocols: IPv4
IPv6
Parental Controls: URL Filtering
Time Controls
WAN Types: Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service: QoS by Device
NAT Forwarding: Port Forwarding
Port Triggering
DMZ
UPnP
IPTV: IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP: Address Reservation
DHCP Client List
Server
DDNS: NO-IP
DynDNS
Management: Webpage
