The Keychron V1 Max QMK/VIA Wireless Custom Mechanical Keyboard delivers peak gaming performance with a 2.4 GHz wireless connection and a 1000 Hz polling rate for ultra-low latency. Easily multitask across three devices via Bluetooth 5.1. Designed with Mac users in mind while ensuring full Windows compatibility, it includes a system toggle and extra keycaps for both operating systems. The gasket mount design with a polycarbonate plate provides a softer, quieter typing experience with enhanced flexibility.

Double-shot PBT keycaps ensure excellent durability and oil resistance, while the south-facing RGB LEDs offer superior illumination without interference. With hot-swappable sockets, you can customize your switches without soldering. QMK/VIA support enables endless key remapping and macro possibilities, all easily managed through the Keychron Launcher web app. The fully assembled version features exclusive Gateron Jupiter switches with an 80-million keystroke lifespan, while PCB-mounted screw-in stabilizers ensure a smooth typing experience with reduced key wobble.

**FEATURES:**

- Customisable keyboard
- 2.4GHz & Bluetooth connection
- ARM architecture MCU with 256K flash
- OSA profile double-shot PBT keycaps
- Gasket mount design with PC plate
- Hot-swappable
- South facing RGB LED lights
- Gateron Jupiter RED switches
- Screw-in PCB stabilisers

**SPECIFICATIONS:**

- Colour: Black
- Material: ABS Plastic
- Plate Material: PC
- Mount Style: Gasket Mount Design
- Battery: 4000 mah rechargeable li-polymer battery
- Charging Time: ± 5 hours
- Bluetooth Version: 5.1
- Compatible System: Windows/macOS/Linux
- N-Key Rollover (NKRO): Yes for both wireless and wired modes
- Hot-swappable : Yes.
- MCU: ARM Cortex-M4 32-bit STM32F402 (256KB Flash)
- Switches: Gateron Jupiter (Fully Assembled Version)
- Backlight: South-facing RGB LED
- Stabiliser: Screw-in PCB stabs
- Charging Port: USB Type-C
- Cable: Type-C cable + Type-A to Type-C adapter
- Operating Environment: -10℃ to 50℃
- Gateron Jupiter RED Switch:
    - Operating force: 45 ± 15 gf
    - Pre-travel: 2 ± 0.6 mm
    - Travel distance: 4mm max.
    - Behavior: Linear
    - Pre-lubed: Yes
    - Sound level: Quiet
    - Suitable for: Office/gaming

**WHAT’S IN THE BOX:**





- Keychron V1 Max QMK/VIA Wireless Custom Mechanical Keyboard | RED Switches – Black x1
- Type-C to Type-C Cable x1
- Type-A to Type-C Cable x1
- Extension Adapter for Receiver x1
- Type-A 2.4GHz Receiver x1
- Type-C 2.4GHz Receiver x1
- Keycap & Switch Puller x1
- Screwdriver x1
- Hex Key x1
