Camera
- Image Sensor 3K CMOS
- Signal System PAL/NTSC
- Max. Resolution 2960 (H) × 1665 (V)
- Min. Illumination 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night 24/7 Color Imaging
- Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Lens
- Lens Type 2.8 mm Fixed focal lens
- Focal Length & FOV 2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°
- Lens Mount M12
Illuminator
- Supplement Light Type White Light
- Supplement Light Range Up to 40 m
- Frame Rate TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps, AHD: 5 MP@20fps, 4 MP@25fps/30fps, CVI: 4 MP@25fps/30fps, CVBS: PAL/NTSC
- Wide Dynamic Range (WDR) Digital WDR
- Image Parameters Switch STD/HIGH-SAT/HIGHLIGHT
- Day/Night Mode Color
- White Balance Auto/Outdoor/Global/Manual
- Image Enhancement DWDR, BLC, HLC, Global, HLS
- Noise Reduction 2D DNR
- Image Settings Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, Smart Light, AGC
Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- Alarm Solid Light Alarm (White Light)
- Audio Built-in mic
General
- Language English
- Operating Condition -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Material Main body: Metal, Enclosure: Plastic
- Communication HIKVISION-C
- Dimension Φ 109.98 mm × 98.27 mm (Φ 4.33″ × 3.87″)
- Weight Approx. 318 g (0.70 lb.)
- Power 12 VDC ± 25%, Max. 3.5 W,*You are recommended to use one power adapter to supply the power for one camera.
Approval
- Protection IP67
