2U rack-mountable USB charger with integrated hub charges and syncs up to 32 tablets, smartphones and other mobile devices. Recommended for schools, offices and other environments where multiple USB devices are used.
- Maximum charge output of 2.4A per USB port
- Supports USB 2.0 data transfer rates up to 480 Mbps
- Syncs any USB device using its compatible software
- Enables future software upgrades to support newer devices
- Mounts in 2U of EIA-standard 19 in. rack
INPUT
Nominal Input Voltage(s) Supported 230V AC
Input Connection Type IEC320-C14
Voltage Compatibility (VAC) 230
Input Frequency 50 / 60 Hz
Input Plug Type C14
Input Cord Length (m) 3.05
Input Current 5A
POWER
Power Consumption (Watts) 112
CONNECTIONS
Number of Ports 32
Side A – Connector 1 (32) USB A (FEMALE)
Side A – Connector 2 USB B (FEMALE)
Side A – Connector 3 (2) MICRO-USB B (FEMALE)
Side B – Connector 1 IEC-320-C14
USER INTERFACE, ALERTS & CONTROLS
LED Indicators Green (32x USB Charging, 1x Sync)
CHARGING
Number of Charging Ports 32
Total Charging Amps 80A
Total Charging Watts 400
Charging Method USB
Charging Port Type USB A (FEMALE)
Charging Ports Details Pass through
Charging Ports / Amps (32) 2.4A
Overcharge Protection Yes
Charging Amps per Port 2.4A
PHYSICAL
Color Black
Material of Construction Steel
Shipping Dimensions (hwd / cm) 20.07 x 42.93 x 50.29
Shipping Weight (kg) 8.35
Unit Dimensions (hwd / mm) 86.7 x 440 x 301.7
Unit Packaging Type Box
Unit Weight (kg) 5.94
Number of Shelves 0
ENVIRONMENTAL
Operating Temperature Range 32° to 104°F (0° to 40°C)
Storage Temperature Range 5° to 122°F (-15° to 50°C)
Relative Humidity 5% to 95% RH, Non-Condensing
AC Mode Efficiency Rating (100% Load) 74.57
BTUs
382.2 BTU/Hr (Full load)
FEATURES & SPECIFICATIONS
Built-In Circuit Breaker Yes
Cord Management No
Overcurrent Protection Yes
EMI/RFI Line Noise Protection Yes
Flow-Through Ventilation Yes
UV Sterilization No
Driver Required No
