Premium Dual Chamber Pump

Fine Tuned Performance Ratio

Superior Heat Exchange

Low Profile Radiator

Redesigned Flux Series Fan

Dual Loop ARGB Pump

## COOLING UNCOMPROMISED

Cooler Master’s Flux Series is the materialization of revolutionary cooling performance. With enhancements from the pump to the radiator and fans, the Flux Series delivers precisely tuned performance for superior heat dissipation and cooling capabilities.

## PREMIUM DUAL CHAMBER PUMP

New Dual Chamber Pump more compact than before while delivering the perfect volume of flow to pressure for impressive cooling performance.https://files.coolermaster.com/product/coolers/cpu-liquid-coolers/masterliquid-pl-flux-series/pump-flow-animation/ml-pl-flux-revise-flow.html

## FINE TUNED PERFORMANCE RATIO

Precision engineered ultra-thin spaded fins maximize microchannels to accurately target heat spots. Enlarged copper base surface area with optimized base thickness further accelerates heat transfer.https://files.coolermaster.com/product/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/html/s0402\_i.html

## ULTIMATE HEAT EXCHANGE

High speed motor utilizing a ceramic bearing impeller forces balanced water flow to and from the radiator for ultimate efficiency of heat exchange.

## SLIM & SLEEK RADIATOR

Low profile radiator with superior fin density coupled with performance fans dissipates heat rapidly.https://files.coolermaster.com/product/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/html/s0602\_i.html


## REDESIGNED FLUX SERIES FAN

Unique air balance fan featuring interconnecting blades specifically designed for the Flux Series. Strengthened structure provides better stability for steady high speed operation. Angled inner fan frame rim boosts air intake, with frame gap generating increased air pressure for improved cooling.https://files.coolermaster.com/product/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/html/s0802\_i.htmlhttps://files.coolermaster.com/product/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/html/s0803\_i.html

## DUAL LOOP ARGB PUMP

Dual loop pump ARGB with independent lighting customization showcases your visual creativity without sacrificing cooling capability.

## ADDRESSABLE GEN 2 RGB

Included Addressable Gen 2 RGB controller works with Cooler Master’s MasterPlus+ software to customize individual LED colors, effects, brightness and more – all from an intuitive, convenient interface.

- [SPECIFICATIONS](https://www.coolermaster.com/catalog/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/#specifications)



| Product Number MLY-D24M-A23PZ-R1 |
| --- |
| Exterior Color Black |
| CPU Socket LGA1700, LGA1200, LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1, TR4 |
| Radiator Material Aluminum |
| Radiator Dimensions 277 x 119.6 x 27.2 mm / 10.7 x 4.7 x 1.07 inch |
| Pump Dimensions 89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch |
| Pump MTTF>210,000 hours |
| Pump Noise Level 15 dBA (Max) |
| Pump Connector 4-Pin (PWM) |
| Pump Rated Voltage 12 VDC |
| Pump Power Consumption 6W |
| Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| Fan Quantity 2 PCS |
| Fan LED Type Addressable Gen 2 RGB |
| Fan Speed 0-2300 RPM ± 10% |
| Fan Airflow 72.37 CFM (Max) |
| Fan Noise Level 32 dBA |
| Fan Pressure2.96 mm H₂O (Max) |
| Fan Bearing Type ORBS |
| Fan Life Expectancy>160,000 Hours |
| Fan Power Connector 4-Pin (PWM) |
| Fan Rated Voltage 12VDC |
| Fan Rated Current 0.15A |
| Fan Safety Current 0.3A |
| RAM Clearance N/A |
| Warranty 5 years |
| Series Master Liquid Pro |
| Cooler Type Liquid Cooler |
| Radiator Size 240 |

More info :[ https://www.coolermaster.com/catalog/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/](< https://www.coolermaster.com/catalog/coolers/cpu-liquid-coolers/masterliquid-pl240-flux/>)
