HAF 700 EVO unveils a new era of thermal efficiency through unique features designed to transcend the standards of contemporary cooling solutions.

Rediscover PC DIY: a form of entertainment, a polished skillset, an exquisite art form, and a way of living.

Exterior Color: Titanium Grey
Materials – Exterior: Mesh, Steel, Plastic
Materials – Left Side Panel: Tempered Glass, Steel
Dimensions (L x W x H): 556 x 279 x 540 mm (Body Size), 666 x 291 x 626 mm (incl. Protrusions)
Motherboard Support: Mini ITX, Micro ATX, ATX, E-ATX, SSI CEB, SSI EEB
Expansion Slots: 8
5.25″ Drive Bays: N/A
2.5″ / 3.5″ Drive Bays (Combo): 12
2.5″ Drive Bays: 12
I/O Panel – USB Ports: 1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0)
I/O Panel – Audio In / Out: 1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack
I/O Panel – Other: 1x LED Controller A1 (ARGB Gen 2), 1x ARGB/PWM Hub
Pre-installed Fans – Front: 2x SickleFlow PWM Performance Ed. 200mm
Pre-installed Fans – Rear: 2x SickleFlow PWM ARGB 120mm
Pre-installed Fans – Bottom: 1x SickleFlow PWM ARGB 120mm
Fan Support – Top: 2x 200mm, 3x 140mm, 6x 120mm (Remove 480mm bracket)
Fan Support – Front: 2x 200mm, 3x 120/140mm
Fan Support – Rear: 2x 120mm
Fan Support – Bottom: 3x 120/140mm
Fan Support – Side: 4x 120mm / 3x 140mm
Radiator Support – Top: Up to 2x 360mm / 1x 420mm
Radiator Support – Front: Up to 420/360mm
Radiator Support – Rear: Up to 240mm
Radiator Support – Bottom: Up to 420/360mm
Radiator Support – Side: Up to 480/420mm
Clearance – CPU Cooler: 166mm / 6.53 inch
Clearance – PSU: 200mm / 7.87″
Clearance – GFX: 490mm
Cable Routing – Behind Motherboard Tray: 90-101mm
Included Accessories: Vertical Graphics Card Holder V3 (Include 165mm PCIe 4.0 Riser Cable)
Dust Filters: Front, Bottom, Side
Power Supply Support: Bottom Mount, ATX
Note: \* For regular 30mm thick radiators, for thicker please reference user manual.
Series: HAF Series
Size: Full Tower
