Aerocool KCAS 850W RGB Power Supply – 80 Plus Gold

• 80Plus Gold Certified for up to 92%+ efficiency
• Compatible with Addressable RGB motherboards using ARGB connector
• DC-to-DC conversion circuit for higher efficiency and tight voltage regulation even under heavy crossloading conditions
• Built-in 105°C Japanese main capacitors provide low ripple and higher durability
• Dual CPU power connectors allows for compatibility with high-end AMD Ryzen CPUs
• 12cm high-pressure fan with optimized fan speed allows for near inaudible fan noise and silent PSU
  operation
• Built-in APFC (Active Power Factor Correction) rates > 0.9
  850W, 80Plus Gold Certified, Ø 12cm ARGB fan, 20+4 Pin Motherboard connector
  Aerocool KCAS PLUS GOLD 850W. Total power: 850 W, AC input voltage: 100 – 240 V, AC input
  frequency: 47 – 63 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular.
  Purpose: PC, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 12 cm, Number of
  fans: 1 fan(s). Certification: ROHS

Power
Total power * 850 W
AC input voltage * 100 – 240 V
AC input frequency 47 – 63 Hz
Input current 11 – 5.5 A
Combined power (+3.3V) 130 W
Combined power (+12V) 840 W
Combined power (+5V) 130 W
Combined power (-12V) 3.6 W
Combined power (+5Vsb) 12.5 W
Max output current (+3.3V) 20 A
Max output current (+12V) 70 A
Max output current (+5V) 20 A
Max output current (-12V) 0.3 A
Max output current (+5Vsb) 2.5 A
Efficiency 92%

Ports & interfaces
Motherboard power connector * 20+4 pin ATX
Number of SATA power connectors 8
Number of PATA power connectors 4
PCI Express power connectors (6+2
pin) 3
CPU power connector (4+4 pin) ✔
Cabling type Non-Modular
Performance
80 PLUS certification * 80 PLUS Gold
Purpose * PC
ATX version 2.52
Design
Product colour Black
Fan diameter 12 cm
Number of fans 1 fan(s)
Illumination ✔
Certificates
Certification ROHS
